The following is the introduction of high quality Physiotherapy instrument PCBA, hoping to help you better understand how to design it. Welcome new and old customers to continue to cooperate with Unixplore Electronics to create a better future!
Physiotherapy instrument PCBA control board is the core part of the physiotherapy instrument. It usually includes power circuits, control circuits, therapeutic circuits, and display circuits.

The power circuit mainly provides electrical energy for physical therapy instruments, and has protection functions, such as overcurrent protection and overvoltage protection.

Control circuit is responsible for the control of the entire physical therapy instrument, including treatment time, treatment mode and treatment intensity. It implements treatment by controlling the treatment circuit.

The treatment circuit is the core part of the physical therapy instrument. It outputs the treatment energy according to the instructions of the control circuit to achieve the treatment effect. Different physical therapy instruments have different therapeutic circuits, such as the electrotherapy circuit of the mid -frequency therapy instrument, and the infrared launch circuit of the infrared therapy instrument.

The display circuit shows the treatment information and parameters, which is convenient for patients to view and understand.

When designing a physiotherapy instrument circuit board, the following aspects need to be considered:

Safety and reliability: Physiotherapy instruments are equipment for treatment. Therefore, the design of the circuit board needs to ensure safety and reliability and avoid accidents.
Accuracy and stability: Physiotherapy instruments need to accurately output the treatment energy, so the design of the circuit board needs to ensure accuracy and stability to ensure the treatment effect.
Easy to produce and maintain: The design of the circuit board of the physiotherapy instrument needs to be considered as easy to produce and maintain, such as the selection of device, the layout and structure of the circuit board, which will directly affect production efficiency and maintenance costs.
Appearance design: The design of the medical therapy instrument board also needs to consider the design, including the size, shape, color of the circuit board, to meet the needs and aesthetics of users.
Unixplore provides one-stop turnkey service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!
